RAZORWELD™ 350W MIG/TIG/MMA Welder

415V THREE-PHASE | SEPARATE WIRE FEEDER | SPOOL GUN READY

This heavy-duty workshop unit guarantees premium welds and unmatched performance, even in the most challenging conditions.

A separate wire feeder gives extra manoeuvrability
Push-Pull gun ready for heavy-duty welding
4 geared wire drive system for the smoothest wire feeding experience
Next-Generation Welding Performance

DSP Arc Control – High-speed digital signal processing continuously regulates voltage and current for superior arc stability.
Reduced Spatter – Optimised droplet transfer minimises post-weld cleanup and consumable waste.
Enhanced Short-Arc Stability – Improved control during short-circuit MIG delivers smooth arc recovery for cleaner starts and finishes.
Controlled Heat Input – Maintains stable penetration across different material thicknesses and joint configurations
Consistent Penetration – DSP helps maintain stable heat input across varied materials and joint conditions.

INTELLIGENT ARC CONTROL
The ARM+DSP dual microprocessor system instantly adapts to welding conditions, providing better control from start to finish.
Driven by an advanced ARM + DSP dual microprocessor platform, the system intelligently adjusts the arc in real time – ensuring smoother control, consistent performance, and confidence from start to finish.

• ARM – Advanced ARM microprocessor provides rapid data processing and intelligent voltage and current regulation for superior arc stability.
• DSP – Advanced DSP (Digital Signal Processing) Arc Control actively manages the welding arc in real-time for a smoother, more responsive weld.

MACHINE SPECIFICATIONS
PRIMARY INPUT VOLTAGE
415V Three Phase
SUPPLY PLUG
32 AMP
Ieff (A)
13.9
Imax (A)
25.0
NO LOAD VOLTAGE (V)
75
PROTECTION CLASS
IP23S
INSULATION CLASS
H
MINIMUM GENERATOR (kVA)
23.0
DINSE CONNECTOR
35/50
STANDARD
AS/NZ60974-1
SUITABLE MATERIAL
Mild Steel, Stainless Steel, Cast Iron, Silicon Bronze, Aluminium, Copper
WARRANTY (Years)
5
MIG Specifications
MIG WELDING CURRENT RANGE
30-350A
MIG DUTY CYCLE @ 40°C
50% @ 350A | 60% @ 319A | 100% @ 247A
MIG WIRE SIZE RANGE
0.6-1.2mm
MIG WIRE SPOOL SIZE
5kg / 15kg
MIG WELDING THICKNESS RANGE
1-16mm
DRIVE ROLLER SIZE
37/24
TIG SPECIFICATIONS
TIG FUNCTION TYPE
DC Lift Arc
TIG WELDING CURRENT RANGE
20-350A
TIG DUTY CYCLE @ 40°C
50% @ 350A | 60% @ 319A | 100% @ 247A
TIG WELDING THICKNESS RANGE
1-10mm
STICK SPECIFICATIONS
STICK WELDING CURRENT RANGE
20-350A
STICK DUTY CYCLE @ 40°C
50% @ 350A | 60% @ 319A | 100% @ 247A
STICK ELECTRODE RANGE
2.5-4.0mm
STICK WELDING THICKNESS RANGE
2-16mm
Size & Weight
DIMENSIONS (mm)
1520 x 520 x 980mm
WEIGHT (kg)
43.4
SWF WEIGHT (kg)
17.8
SWF INTERLOCKING CABLE LENGTH (m)
10m
MACHINE FEATURES
WIRE DRIVE
Seperate 4 Geared
SPOOL GUN CONNECTION
Yes
PUSH / PULL GUN CONNECTION
Yes
BURNBACK ADJUSTMENT
Automatic
WIRE INCH
Yes
INDUCTANCE CONTROL
Yes
THERMAL OVERLOAD PROTECTION
Over Temperature Warning
